Design
Maverick is an American-made fat bike with modern trail geometry and massive tires. Its roomy cockpit is made for short stems and wide bars for better control over the big front tire. The slack head tube angle, low bottom bracket, and optimized chain stay lengths make for a balanced ride to keep you feeling confident on the steep downhill sections and allow you to climb like a mountain goat on those daunting hills. Maverick is designed for having fun whenever and wherever you ride.
The Foundation (Frame Design)
You’ve probably noticed, but our frames have a unique look to them. They are burly, aggressive, and made to take a beating. We only use premium US-sourced 6061-T6 aluminum for a great balance of strength and weight. The front triangle is made with oversized round tubing, while the rear triangle is made from custom extruded rectangular tubing welded to CNC’d yokes and sliding dropouts. This design reduces frame flex, improves torsional compliance, and enhances power transfer with each pedal stroke. In other words, less energy is absorbed in the frame and more energy is transferred from the tire to the ground.
Suspension Friendly
The Maverick is designed around a 530mm axle to crown fork. This is the length of the fork from the center of the axle to the top of the crown. For fat bike forks, this is typically 110-120mm of travel depending on the brand and model year. This is why it is important to look at the axle to crown number rather than the travel numbers when determining if a fork will fit or affect the geometry of the bike. The Wren Carbon fork is suspension-corrected for the Maverick and is equal to a 110mm fork at 20% sag, so the geometry and ride quality aren’t adversely affected when switching between the two forks.
Adjustable Dropouts
The Maverick frame is equipped with the tried and true sliding dropout system. Our sliding dropouts allow you to move your wheel fore and aft with 20mm of adjustment. This allows you to modify your chainstay length, use different tire size diameters, and even run your bike setup as a single speed. Ultimately, this allows you to tune your bike for different riding scenarios. And yes, our dropouts are compatible with all Paragon Machine Works’ conventional sliders and Sram’s Transmission group.
Dropper Post Compatible
Whether you want to keep it simple with a rigid post or want to benefit from the use of a dropper post, the Maverick is compatible with both internal and externally routed dropper posts. There is a slot in the bottom of the seat tube that allows for an internally routed dropper post or you can use the additional mounts under the top tube to route an externally routed dropper post. The choice is yours!
Narrow Q-Factor Compatible
The Maverick has a 100mm threaded bottom bracket, which is 20mm narrower than most fat bikes with 197mm of rear spacing. Our newly designed CNC yokes and curved chainstays allow you to use any fat bike crankset designed for 190/197mm rears with a Q-factor of 205mm or greater. Please note that the stock RaceFace Ride crankset has a 230mm Q-factor.
Massive Tire Clearance
Maverick was built around a 26″ x 4.8″ tire, which is our preferred tire for optimal handling on loose trails. But this size might not be for everyone. Want to run 26″ x 5.05″ tires? No problem. What about 27.5″ x 4.5″ tires? Piece of cake. Hey, what if I want to run 29″ x 3.0″ tires? Easy peasy. We achieved this with our beautifully designed CNC yokes and sliding dropouts mated to our sexy curved rectangular chainstays and seat stays.
Tire Compatibility
Build Kit
Frameset | |
Frame | Premium 6061-T6 Aluminum (Made in USA) |
Fork | Wren Rigid or Wren Inverted Suspension |
Dropouts | Sliders, 20mm adjustable, 197x12mm |
Wheelset | SUNringlé Mulefüt V2 26" |
Tires | Schwalbe Al Mighty 26x4.8" |
Drivetrain | Your choice |
Crank | RaceFace Ride 170mm |
Chainring | RaceFace DM N/W Steel 30t |
Bottom Bracket | RaceFace Team XC 100mm Threaded |
Saddle | WTB Speed Comp |
Seatpost | Raceface Ride 30.9mm |
Handlebar | ProTaper 31.8 x 800 |
Stem | Protaper, Length: 35mm, Clamp: 31.8mm |
Grips | ODI |
Headset | FSA Orbit ITA - tapered |
Brakeset | Your choice |
Rotors | 180mm front / 160mm rear |
Pedals | Optional |
Weight | Medium w/Carbon Fork - 32 lbs Medium w/Suspension - 36 lbs |
Weight limit | 350lbs |
Frame Specs
Frame Material: American-made 6061-T6 aluminum
Bottom Bracket: 100mm Threaded
Chainline: 76mm
Q-factor: 230mm (w/RF Ride Crankset) / Frame is compatible with lower Q-factor cranksets with a 205mm Q.
Minimum Q-factor: 205mm (228mm for frames ordered in 2022)
Max Chainring: 34t
Rear Spacing: 12 x 197mm (Stock) / 9 x 190mm (with QR sliders)
Dropouts: Left Side, Sliding, Post Mount, 160 Rotor, 12 mm | Right Side, Sliding, Hanger, M12 x 1.5
Rear Axle: 197 x M12 x 1.5, Rear
Headtube: 50.8mm OD / 44mm ID
Seat Tube: 34.9mm OD / 30.9mm ID (31.6mm if the bike was received in 2022)
Seat Post Clamp Diameter: 34.9mm
Recommended Tire Size: 26 x 4.8″ / 27.5 x 3.8″ / 29 x 3.0″
Max Tire Size: 26 x 5.05″ / 27.5 x 4.5″
Water Bottle Mounts: 2 locations (above and below down tube)
Rack Mounts: Located on rear dropouts (Special seat clamp required for seat tube mount)
Weight: 6 lbs (with sliders)
Frame Size Guide
Please review the size chart below to determine the optimal frame size based on your height.
If you find yourself between sizes, we recommend the following:
- Size down for an active ride and size up for a stable ride.
- If you have longer legs and a shorter torso than the average person your height, we recommend that you size down. If you’re all torso and arms, we recommend that you size up.
Geometry
The Maverick frame has modern mountain bike geometry and is based around a front fork with an axle to crown of 530mm. You will find our base Geometry under the Wren Inverted 110mm tab below. We’ve also included the geometry charts for the different fork options that we offer, along with how a 20% sag setting adjusts the geometry numbers.
Please keep in mind that when comparing geometry charts between two brands, many factors come into play that can alter the charts. The biggest factor is fork length and fork offset, which can alter the stack and reach numbers significantly. Other variables that can affect the stack and reach numbers include head tube length and lower headset stack height. Another important factor to keep in mind when looking at the reach numbers is stem length. A frame might have a long reach, but it was designed to use a short stem, like the Maverick.
If you have any questions about our frame sizing or geometry, please don’t hesitate to contact us.
Maverick Geometry with the Wren Rigid Carbon fork
Bike Size | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
A | Effective Top Tube Length | 616mm | 647mm | 685mm | 712mm |
B | Reach | 447mm | 477mm | 512mm | 537mm |
C | Stack | 636mm | 639mm | 650mm | 658mm |
D | Seat Tube Length | 400mm | 440mm | 490mm | 540mm |
E | Seat Tube Angle | 75° | 75° | 75° | 75° |
F | Head Tube Length | 115mm | 125mm | 135mm | 145mm |
G | Head Tube Angle | 68° | 68° | 68° | 68° |
H | Chainstay Length | 445-465mm | 445-465mm | 445-465mm | 445-465mm |
J | Stand Over Height | 27.5" | 28.5" | 29.5" | 31.5" |
K | Bottom Bracket Drop | 63mm | 63mm | 63mm | 63mm |
M | Wheelbase | 1166-1186mm | 1198-1218mm | 1237-1257mm | 1266-1286mm |
N | Front Center | 728mm | 760mm | 799mm | 828mm |
O | Fork Length | 505mm | 505mm | 505mm | 505mm |
P | Fork Offset | 45mm | 45mm | 45mm | 45mm |
Maverick Geometry with Wren Inverted 110mm without sag
Bike Size | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
A | Effective Top Tube Length | 620mm | 651mm | 688mm | 716mm |
B | Reach | 435mm | 465mm | 500mm | 525mm |
C | Stack | 640mm | 649mm | 658mm | 668mm |
D | Seat Tube Length | 400mm | 440mm | 490mm | 540mm |
E | Seat Tube Angle | 74° | 74° | 74° | 74° |
F | Head Tube Length | 115mm | 125mm | 135mm | 145mm |
G | Head Tube Angle | 67° | 67° | 67° | 67° |
H | Chainstay Length | 445-465mm | 445-465mm | 445-465mm | 445-465mm |
J | Stand Over Height | 28" | 29" | 30" | 32" |
K | Bottom Bracket Drop | 55mm | 55mm | 55mm | 55mm |
M | Wheelbase | 1175-1195mm | 1208-1228mm | 1246-1266mm | 1275-1295mm |
N | Front Center | 736mm | 768mm | 807mm | 835mm |
O | Fork Length (Axle to Crown) | 530mm | 530mm | 530mm | 530mm |
P | Fork Offset | 45mm | 45mm | 45mm | 45mm |
Maverick Geometry with Wren Inverted 110mm with 20% sag
Bike Size | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
Recommended Rider Height | 5'3"-5'7" | 5'8"-5'11" | 6'0"-6'3" | 6'4"-6'7" | |
A | Effective Top Tube Length | 617mm | 648mm | 685mm | 713mm |
B | Reach | 446mm | 476mm | 510mm | 535mm |
C | Stack | 637mm | 641mm | 650mm | 659mm |
D | Seat Tube Length | 400mm | 440mm | 490mm | 540mm |
E | Seat Tube Angle | 75° | 75° | 75° | 74° |
F | Head Tube Length | 115mm | 125mm | 135mm | 145mm |
G | Head Tube Angle | 68° | 68° | 68° | 67° |
H | Chainstay Length | 445-465mm | 445-465mm | 445-465mm | 445-465mm |
J | Stand Over Height | 28" | 29" | 30" | 32" |
K | Bottom Bracket Drop | 62mm | 62mm | 62mm | 62mm |
M | Wheelbase | 1167-1187mm | 1199-1119mm | 1238-1258mm | 1267-1287mm |
N | Front Center | 730mm | 761mm | 800mm | 828mm |
O | Fork Length (Axle to Crown) | 508mm | 508mm | 508mm | 508mm |
P | Fork Offset | 45mm | 45mm | 45mm | 45mm |
Maverick Geometry with Wren Inverted 120mm without sag
Bike Size | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
A | Effective Top Tube Length | 621mm | 652mm | 690mm | 718mm |
B | Reach | 429mm | 460mm | 495mm | 520mm |
C | Stack | 643mm | 652mm | 662mm | 671mm |
D | Seat Tube Length | 400mm | 440mm | 490mm | 540mm |
E | Seat Tube Angle | 73.6° | 73.6° | 73.6° | 73.6° |
F | Head Tube Length | 115mm | 125mm | 135mm | 145mm |
G | Head Tube Angle | 66.6° | 66.6° | 66.6° | 67° |
H | Chainstay Length | 445-465mm | 445-465mm | 445-465mm | 445-465mm |
J | Stand Over Height | 28.5" | 29.5" | 30.5" | 32.5" |
K | Bottom Bracket Drop | 51mm | 51mm | 51mm | 51mm |
M | Wheelbase | 1180-1200mm | 1211-1231mm | 1250-1270mm | 1279-1299mm |
N | Front Center | 740mm | 771mm | 810mm | 839mm |
O | Fork Length (Axle to Crown) | 540mm | 540mm | 540mm | 540mm |
P | Fork Offset | 45mm | 45mm | 45mm | 45mm |
Maverick Geometry with Wren Inverted 120mm with 20% sag
Bike Size | Small | Medium | Large | X-Large | |
---|---|---|---|---|---|
A | Effective Top Tube Length | 618mm | 649mm | 687mm | 714mm |
B | Reach | 442mm | 472mm | 506mm | 531mm |
C | Stack | 635mm | 644mm | 653mm | 662mm |
D | Seat Tube Length | 400mm | 440mm | 490mm | 540mm |
E | Seat Tube Angle | 74.6° | 74.6° | 74.6° | 74.6° |
F | Head Tube Length | 115mm | 125mm | 135mm | 145mm |
G | Head Tube Angle | 67.6° | 67.6° | 67.6° | 67.6° |
H | Chainstay Length | 445-465mm | 445-465mm | 445-465mm | 445-465mm |
J | Stand Over Height | 28.5" | 29.5" | 30.5" | 32.5" |
K | Bottom Bracket Drop | 60mm | 60mm | 60mm | 60mm |
M | Wheelbase | 1170-1190mm | 1202-1222mm | 1241-1261mm | 1270-1290mm |
N | Front Center | 732mm | 763mm | 802mm | 831mm |
O | Fork Length (Axle to Crown) | 516mm | 518mm | 518mm | 518mm |
P | Fork Offset | 45mm | 45mm | 45mm | 45mm |
